Victron Orion-Tr 24|12-20 DC-DC Converter, 240W non-isolated step-down converter
The Victron Orion 24|12-20 240 W DC-DC converter provides a constant DC voltage, thereby ensuring uninterrupted operation of your DC loads. The 24|12 converts 24 V DC to 12 V DC at a constant 20 A (240 W). It also compensates for any conductor losses and fluctuations in battery voltage.
Features:
Model: Orion-Tr 24|12-20 non-isolated;
Input voltage range: 18–35 V;
Efficiency: 97 %;
Nominal output voltage: 12.5 V;
Continuous output current: 20 A;
Maximum output current: 25 A;
Galvanic isolation: no;
No-load current: < 35 mA;
Operating temperature range (3% derating per °C above 40°C): -20 to +55 ºC;
DC connection: Screw terminals;
Maximum cable cross-section: 6 mm² (AWG10);
